OWON AG 1022F Arbitrary Wave Function Generator


33,150.00

Compare

Arbitrary Wave Function Generator, 25 MHz,2 CH,Coloured LCD,USB+,Owon

  • Advanced DDS technology
  • Up to 250MS/s sample rate, and 1μHz frequency resolution
  • Comprehensive waveform output : 5 basic waveforms, and 45 built-in arbitrary waveforms
  • Comprehensive modulation functions : AM, FM, PM, FSK, PWM, Sweep, and Burst
  • High-accuracy frequency counter integrated, supported range 100mHz – 200MHz
  • Supported SCPI
  • 4 inch high resolution (480 × 320 pixels) TFT LCD display
Category: Tags: , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,
Weight 4 kg

Channel dual
Frequency Output 25MHz
Sample Rate 125MS/s
Vertical Resolution 14 bits
Waveform: Standard Waveform Sine, Square, Pulse, Ramp, and Noise
Arbitrary Waveform: Exponential Rise, Exponential Fall, Sin(x)/x, Step Wave, and others,
total 26 built-in waveforms, and other user-defined arbitrary waveforms

Frequency (resolution 32 bits)
Sine 1μHz – 25MHz
Square 1μHz – 5MHz
Pulse 1μHz – 5MHz
Ramp 1μHz – 1MHz
Noise 25MHz (-3dB) (typical)
Arb 1μHz – 10MHz

Amplitude: 1m Vpp – 10 Vpp (50Ω), 1m Vpp – 20 Vpp (high impedance)
Resolution 1m Vpp or 14 bits
DC Offset Range (AD+DC) ±5V (50Ω), ±10V (high impedance)
DC Offset Range Resolution 1mV
Load Impedance 50Ω (typical)

Arbitrary Waveform
Wave Length 2 pts to 8K pts
Sample Rate 125MS/s
Vertical Resolution 14 bits
Non-volatile Memory 26 waveforms
Modulation
Modulation Waveform AM, FM, PM, FSK, Sweep, and Burst
Modulation Frequency 2mHz to 20.00KHz (FSK 1μHz – 100KHz)
Counter
Function Frequency Period, +Width, -Width, +Duty, and -Duty
Frequency Range 100mHz – 200MHz
Frequency Resolution 6 digits/s
Input / Output
Display 3.9 inch (480 × 320 pixels) TFT LCD
Type
counter, external modulation input / output, external trigger input / output,
external reference clock input / output
Communication Interface USB host, USB device, RS232
Mechanical
Dimension (W×H×D) 235 × 110 × 295 (mm)
Weight (without package) 3.00 kg

Warranty: As per Owon – 1 Year
