DC Voltage (V) 220mV/2.2V/22V/220V/1000V ±(0.1% 2)
AC Voltage (V) 220mV/2.2V/22V/220V/750V ±(0.8% 10)
DC Current (A) 200μA/2200μA/22mA/220mA/2.2A/10A ±(0.5% 10)
AC Current (A) 200μA/2200μA/22mA/220mA/2.2A/10A ±(0.8% 10)
Resistance (Ω) 220Ω/2.2kΩ/22kΩ/220kΩ/2.2MΩ/22MΩ/220MΩ ±(0.5% 10)
Capacitance (F) 22nF/220nF/2.2μF/22μF/220μF/2.2mF/22mF/220mF ±(3.0% 5)
Frequency (Hz) 10Hz-220MHz ±(0.01% 5)
Display Count 　 22000
Auto Range 　 √
True RMS 　 √
Bandwidth (Hz) 　 45Hz ～10kHz
Duty Cycle 0.1% ～ 99.9% √
Diode 　 √
Continuity Buzzer 　 √
Low Battery Indication ≤7.5V √
Data Hold 　 √
Relative Mode 　 √
MAX/MIN 　 √
Peak Value 　 √
RS-232 　 √
Analog Bar Graph 　 46
Input Protection 　 √
Input Impedance for DCV Around 10MΩ √
General Characteristics
Power 9V Battery (6F22)
LCD Size 65mm X 43mm
Product Color Red and grey
Product Net Weight 370g
Product Size 180mm X 87mm X 47mm
